HDMI Matrix Switcher

HDMI 8x8 4K Matrix Switcher with Audio Matrix/ Downscaling

VLHDMIMAT8X8 is a professional 8x8 HDMI 2.0 Matrix Switcher with Video
Audio Matrix. It includes 8 HDMI inputs, 8 HDMI outputs and the HDMI output resolution Up to 4K@60Hz 4:4:4, HDR10 and Dolby Vision
last four outputs with down-scaling function, which is designed for HDMI output Supports up to 5V500mA for AoC cable
switching four HDMI2.0 and HDCP2.3 compliant signals. It also features HDMI version Up to 2.0
8 SPDIF and 8 analogue audio outputs for audio matrix. HDCP version Up to 2.3
The matrix switcher features comprehensive EDID management and LPCM 7.1 audio, Dolby Atmos®, Dolby® TrueHD, Dolby
advanced HDCP handling to ensure maximum functionality with a HDMI audio signal Digital® Plus, DTS:X™, and DTS-HD® Master Audio™
wide range of video sources. pass-through.
Digital audio output
Output (8) Digital SPDIF audio
The matrix switcher not only supports bi-directional IR, RS232
extension, but also has IR, RS232, and TCP/IP control options. Output connector (8) Toslink connector
Digital SPDIF audio format Supports PCM, Dolby Digital, DTS, DTS-HD
Frequency response 20Hz – 20KHz,±1dB
PART NO.
Max output level ±0.05dBFS
HDMI 2.0 8x8, Matrix switcher VLHDMIMAT8X8
Analogue audio output
• 8x8 HDMI 2.0 Matrix Switcher Output (8) Analog L/R Audio
• Supports 4K@60Hz 4:4:4, HDR, HDCP2.3 compliant Output connector (8) L&R (RCA)
• Audio Matrix, audio out can be de-embedded from arbitrary Digital SPDIF audio format PCM 2CH
input or output Frequency response 20 Hz to 20 kHz, ±1dB
Control
• Individual volume adjustment on each L+R output
Control port (1) FIRWARE, (1) IR EYE, (1) RS232, (1) TCP/IP, Video Scaler & Matrix
• Supports 4K to 1080p down-scaling up to 4 outputs (1) USB-A, (1) 3.5mm jack, (1) 3-pin terminal block,
• HDMI out provides 2.5W to power Active Optical Cable (AOC) Control connector (1) RJ45
• HDMI Output support up to 5V500mA for AOC cable General
Bandwidth 18Gbps
• Controllable by front panel, IR, RS232 and TCP/IP
Power consumption
Vivolink keeps your system running 24W
Dimension (W*H*D)
If you face any problems with your Vivolink product, we 436.4mm*44mm*236mm
immediately send you a new one. No need to wait for a
Free Swap faulty product to be repaired.
Net weight
Back Warranty This is part of our Premium Professional Service. 3kg
Front
