HDBaseT Matrix Switcher

4x4 HDMI 2.0 HDBaseT Matrix Switcher Input Connector (4) Type-A female HDMI
Output (4) HDBaseT, (4) HDMI
VLHDMIMAT4X444 is a four-input by four-output HDBaseT and HDMI Up to 4Kx2K@60Hz 4:4:4, HDR10, 1080p 3D.
matrix with HDCP 2.2 and up to 4K/UHD@60Hz video support. It HDMI Output Resolution Supports 4K to 1080p down-scaling.
transmits 4K video to distances up to 40 metres and 1080p video to HDBaseT Output Resolution Up to 4Kx2K@60Hz 4:2:0
distances up to 70 metres over a single CAT6a Ethernet cable. LPCM 7.1 audio, Dolby Atmos®, Dolby® TrueHD, Dolby
The four HDBaseT outputs support 24V Power over Cable (PoC) HDMI Audio Signal Digital®
feature, allowing the receivers to draw their power from the matrix Plus, DTS:X™, and DTS-HD® Master Audio™
over the HDBaseT cable. Output pass-through
(4) Stereo analogue L+R audio, (4) Digital SPDIF audio
PART NO.
Digital SPDIF Audio Format Supports PCM, Dolby Digital, DTS, DTS-HD
HDBaseT Matrix Switcher VLHDMIMAT4X444 Local Audio Sampling Rate Supports 44.1KHz, 48KHz, 96KHz
Receiver for VLHDMIMATX444 VLHDMIMAT4X444-R
Frequency Response 20Hz – 20KHz, ±3dB
• 4x4 HDBaseT matrix switcher with audio matrix (4) IR IN, (1) IR ALL IN, (4) IR OUT, (1) IR ALL OUT, (1)
IR EYE
• Fully compliant with the HDMI 2.0 and HDCP 2.2 Control port
(5) RS232, (1) FIRWARE, (1) TCP/IP
• Supports HDMI resolution up to 4K@60Hz 4:4:4, HDR10 Transmission Mode HDBaseT
• Features four mirrored HDMI outputs for four HDBaseT outputs, and the 1080p ≤ 230 feet (70 metres),
Transmission Distance
four HDMI outputs support 4K to 1080p down-scaling 4K@60Hz ≤ 131 feet (40 metres)
• The four HDBaseT outputs support 24V PoC, allowing the receivers to Bandwidth 18Gbps
draw their power from the matrix switcher over the HDBaseT cable Operation Temperature -5°C ~ +55°C
Storage Temperature -25°C ~ +70°C
• Transmits 4K signal to the distance up to 40 metres and 1080p signal to
Relative Humidity 10% ~ 90%
the distance up to 70 metres over a single CAT6a Ethernet cable
External Power Supply 100V~240V AC, 50/60Hz
• Supports audio matrix. Provides four digital SPDIF audio outputs and Power Consumption 65W (Max) Video Scaler & Matrix

Dimension (W*H*D) 436.4mm x 44mm x 356.6mm
Front
Net Weight 3.3kg
four analogue L+R audio outputs for HDMI input audio de-embedding and
Vivolink keeps your system running
If you face any problems with your Vivolink product, we HDBaseT output audio de-embedding. Moreover, the four digital SPDIF
immediately send you a new one. No need to wait for a Back
Free Swap faulty product to be repaired.
Warranty audio outputs supports ARC audio output from receivers
This is part of our Premium Professional Service.
• Volume adjustment for analogue L+R audio outputs
• Supports comprehensive EDID management and advanced HDC handling
• Controllable via front panel buttons, RS232 local and pass-through, IR local
and pass-through, CEC, and TCP/IP (built-in GUI)

VLHDMIMAT4X444-R
