Scaler/Switchers

HDBaseT Seamless Scaler/Switcher Video input (4)HDMI IN (1~4), (1) DP, (1) USB-C

(4)Type-A female HDMI, (1) DisplayPort,
4K w/multi view Video input connector (1)Type-C USB
HDMI: Up to 4K@30Hz 4:4:4
Input resolution DP: Up to 4K@30Hz 4:4:4
VLSC262 is a true 4K presentation switcher with USB-C: Up to 4K@30Hz 4:4:4
glitch-free source switching. Video output (1)HDMI, (1) HDBaseT
Video output connector (1)Type-A female HDMI, (1) RJ45
Output resolution HDMI: Up to 4K@30Hz 4:4:4
PART NO. HDBaseT: Up to 4K@30Hz 4:4:4
HDMI standard Up to 1.4
4K 6x1 presentation switcher VLSC262
HDCP version Up to 2.2
Audio input (1)LINE, (1) MIC
VLSC262 is a seamless 4x1 (+2 selectable inputs) video scaler switcher Audio input connector (2)3-pin terminal blocks
with 4x HDMI, 1x DisplayPort and 1x USB-C inputs and 1x HDMI, Frequency response 20Hz ~ 20KHz, ±3dB
1x HDbaseT output.
Max input level 2.0Vrms ± 0.1
< 0.3dB, 1KHz sine at 0dBFS level (or max level
It provides seamless and glitch-free switching with advanced scaling L-R level deviation before clipping)
for high quality presentations. Input impedance >10KΩ
LINE/MIC audio format PCM 2.0
With HDBaseT integration, the unit is able to transmit full HD video up HDMI/DP audio format PCM 2.0 48K
to 230ft/70m. Audio output (1)L+R
Audio output connector (1)5-pin terminal block
Frequency response 20Hz ~ 20KHz, ±1dB
Max output level 2.0 ± 0.1Vrms
< 0.05%, 20Hz ~ 20KHz bandwidth, 1KHz sine at
THD+N 0dBFS level (or max level) Video Scaler & Matrix
SNR >80dB, 20Hz ~ 20KHz bandwidth

• Multiview function (can show 4 pictures on one screen)
• True seamless switching
• 6 input 2 output HDBaseT and HDMI mirror
• HDBT output transmission up to 40m@4K and 70m@1080p
• Inputs include 4 HDMI, 1 DP, 1 USB-C (USB-C and DP is
optional with 2 HDMI)
• USB-C can provide 60W power charging
• Supports HDMI1.4, HDCP2.2
• Resolution up to 4K/30Hz/4:4:4 with seamless switching
• Microphone/line input and balance/digital audio breakout
• Audio delay function via front panel
• Manual/auto display control
• IR, RS232 and GUI control.
