TR A NSCEIV ERS

Ruckus Equivalent Transceivers

Ruckus MPN Lanview MPN Form factor Data rate Wavelength Distance Connector Fiber Temp. range Component TX power RX sens Optical power Temp. range DDMI
E40G-QSFP-SR4 MO-RUC-E40G-QSFP-SR4 QSFP+ 40Gb/s 850nm 100m MTP/MPO MM C VCSEL/PIN -7.6~2.4dBm -9.5dBm 1.9dB 0°C ~ 70°C DDMI

E40G-QSFP-LR4 MO-RUC-E40G-QSFP-LR4 QSFP+ 40Gb/s 1270/1290/1310/1330nm 10km LC SM C DFB/PIN -7~2.3dBm -11.5dBm 4.5dB 0°C ~ 70°C DDMI
E40G-QSFP-ER4 MO-RUC-E40G-QSFP-ER4 QSFP+ 40Gb/s 1270/1290/1310/1330nm 40km LC SM C DFB/APD -2.7~4.5dBm -21.2dBm 18.5dB 0°C ~ 70°C DDMI
E40G-QSFP-LM4 MO-RUC-E40G-QSFP-LM4 QSFP+ 40Gb/s 1310nm 2km LC SM C DFB/PIN -7~2.3dBm -13.2dBm 7dB 0°C ~ 70°C DDMI

Ruckus MPN Lanview MPN Form factor Data rate Wavelength Distance Connector Fiber Temp. range Component TX power RX sens Optical power Temp. range DDMI
E100G-QSFP28-SR4 MO-RUC-E100G-QSFP28-SR4 QSFP28 100Gb/s 850nm 100m MTP/MPO MM C VCSEL/PIN -8.4~2.5dBm -5.2dBm 3.2dB 0°C ~ 70°C DDMI

E100G-QSFP28-DR1 MO-RUC-E100G-QSFP28-DR1 QSFP28 100Gb/s 1310nm 500m MTP/MPO SM C VCSEL/PIN -5.4~1.5dBm -4.4dBm 3.9dB 0°C ~ 70°C DDMI
E100G-QSFP28-
CWDM4- MO-RUC-E100G-QSFP28- QSFP28 100Gb/s 1271/1291/1311/1331nm 2km LC SM C DFB/PIN -6.5~2.5dBm -11.5dBm 5dB 0°C ~ 70°C DDMI
2KM CWDM4-2KM

E100G-QSFP28-FR1 MO-RUC-E100G-QSFP28-FR1 QSFP28 100Gb/s 1310nm 2km LC SM C DFB/PIN -5.3~4.2dBm -11dBm 5.4dB 0°C ~ 70°C DDMI
E100G-QSFP28-
LR4- MO-RUC-E100G-QSFP28-LR4- QSFP28 100Gb/s 1296/1300/1305/1309nm 10km LC SM C DFB/PIN -4.3~4.5dBm -10.6dBm 6.3dB 0°C ~ 70°C DDMI
10KM 10KM
