S TRU CT U R ED CA BLING

Copper Structured cabling

Cat6 U-UTP network cable

Used in outdoor structured cabling systems. For transmission of
telecommunications and high speed data.
Lanview Cat6 Unshielded LSZH cables are manufactured and tested
to the ISO/IEC 11801, EIA/TIA 568B and EN50173-2 standards. Each
cable consists of 4x2 colour coded PE insulated conductors.

Specifications:
• Reaction-to-fire class: Eca • 305 m REELEX box
• AWG 23 solid copper • Meter marking on Size (m) Part no.
• EMC Class: B cable 4x2xAWG23 PE black 305m LVN122151

Cat6a U-FTP network cable

Used in outdoor structured cabling systems. Typically used
as intermediate cabling between buildings as well as outdoor
surveillance.

This type of cable has no overall shielding but the individual twisted
pairs are wrapped in a foil screen, offering some protection from EMI
and crosstalk from adjacent pairs and other cables.

Lanview Cat6 U-UTP PE cables are manufactured and tested to the
ISO/IEC 11801, EIA/TIA 568B and EN50173-2 standards. Each cable
consists of 4x2 colour coded PE insulated conductors.

Specifications: Size (mm) Part no.
• UV resistant 4x2xAWG23 PE black outdoor 500m LVN122445
• HD-Base T application
• AWG: 23 solid copper
• 500 m reel
• Meter marking on cable
