S TRU CT U R ED CA BLING

Patch panels

24-port UTP Cat5e + Cat6 patch panel 1U
for 19” rack

19’’ Unshielded Patch Panel designed for EIA and TIA
compliance. The panel has a screen printed label field
positioned above each port, and cable tie bridges are
positioned behind each port to relieve cable stress.
Part no. LVN127596
Backward compatible

Specifications:
• Backward compatible
• EIA and TIA compliance
• Screen printed labeling field
• Cable tie bridges behind each port

24-port UTP Cat6a patch
panel 1U for 19” rack

19’’ Unshielded Patch Panel designed with staggered ports for
minimized alien crosstalk.

The panel has screen printed label field positioned above or
below each port, and cable braces are positioned behind each
port to relieve cable stress.
Part no. LVN127597
Specifications:
• Staggered ports for minimized alien
crosstalk
• Screen printed labeling field
• Cable tie bridges behind each port
• Backwards compatible

24-port STP Cat6 + Cat6a

patch panel 1U for 19” rack

19’’ Shielded Patch Panel designed for shielded
installations.

The panel has a screen printed label field positioned
above each port, and cable tie bridges are positioned
behind each port to relieve cable stress. Part no. LVN127603

Specifications:
• Screen printed labeling field
• Cable tie bridges behind each port
• Backwards compatible

10 4 L A N V I E W ®
