FIBR E CA BLING
Fibre patch panels
Fibre patch panel 19” 1U 24-port Fibre patch panel 19” 1U 24-port
for SC simplex/LC for SC simplex/LC
19’’ fibre patch panel for up to 24 SC simplex or LC 19’’ fibre patch panel for up to 24 SC simplex or LC
duplex adapters. The panel back features 4 Ø18 duplex adapters. The panel back features 4 Ø20
mm inlets suitable for PG screw connection and 2 mm inlets suitable for PG screw connection and 2
rectangular inlets 105 x 20 mm. rectangular inlets 80 x 34 mm with blank plates.
The patch panel has fixtures for splice cassettes and Rubber-coated strain relief suitable for blown-fibre.
cable management cutouts for securing the cables with
cable ties or velcro straps to relieve cable stress. The patch panel have fixtures for splice cassettes and
cable management cutouts for securing the cables with
cable ties or velcro straps to relieve cable stress.
Slide-out Slide-out
design design
Part no. LVO231517 Part no. LVO231544
Fibre patch panel 19” 1U 12-port Fibre patch panel 19” 1U 24-port
for SC duplex/LC quad for SC duplex/LC quad
19’’ fibre patch panel for up to 12 SC duplex or LC 19’’ fibre patch panel for up to 24 SC duplex or LC quad
quad adapters. The panel back side features 4 Ø20 adapters. The panel back side features 4 Ø20 mm inlets
mm inlets suitable for PG screw connection and 2 suitable for PG screw connection and 2 rectangular inlets
rectangular inlets 80 x 34 mm with blank plates. 80 x 34 mm with blank plates.
Rubber-coated strain relief suitable for blown-fibre. Rubber-coated strain relief suitable for blown-fibre.
The patch panel has fixtures for splice cassettes and The patch panel has fixtures for splice cassettes and
cable management cutouts for securing the cables with cable management cutouts for securing the cables with
cable ties or velcro straps to relieve cable stress. cable ties or velcro straps to relieve cable stress.
Slide-out Slide-out
design design
Part no. LVO231551 Part no. LVO231552
