FIBR E CA BLING

Fibre patch panels

Fibre patch panel 19’’ 1U
with 6 x LC duplex single mode

Mounted with 6 x LC duplex single mode adapters. 12
pigtails pre-mounted in splice cassette.

Rubber-coated strain relief suitable for blown-fibre. The
patch panel has fixtures for splice cassettes and cable
management cutouts for securing the cables with cable Specifications:
ties or velcro straps to relieve cable stress. • Slide-out design
• 6 x LC SM blue zirconia adapters included
Part no. LVO233835 • 1 x 24 port splice cassette included
• 12 x steel splice included

Fibre patch panel 19’’ 1U
with 12 x LC duplex

19’’ fibre patch panel for up to 24 SC simplex or LC
duplex adapters. The panel back features 4 Ø20
mm inlets suitable for PG screw connection and
2 rectangular inlets 80 x 34 mm with blank plates.
Mounted with 12 x LC duplex single mode adapters. 24
pigtails pre-mounted in splice cassette. Rubber-coated Specifications:
strain relief suitable for blown-fibre. The patch panel • Slide-out design
has fixtures for splice cassettes and cable management
cutouts for securing the cables with cable ties or velcro • 12 x LC SM blue zirconia adapters included
straps to relieve cable stress. • 1 x 24 port splice cassette included
• 24 x steel splice included
Part no. LVO233840

Fibre patch panel 19’’ 1U
with 24 x LC duplex

19’’ fibre patch panel for up to 24 SC simplex or LC
duplex adapters. The panel back side features 4 Ø20
mm inlets suitable for PG screw connection and
2 rectangular inlets 80 x 34 mm with blank plates.
Mounted with 24 x LC Duplex Single Mode adapters. 48 Specifications:
pigtails pre-mounted in splice cassettes. Rubber-coated • Slide-out design
strain relief suitable for blown-fibre. The patch panel • 24 x LC SM BLue Zirconia adapters included
has fixtures for splice cassettes and cable management
cutouts for securing the cables with cable ties or velcro • 2 x 24 port splice cassettes included
straps to relieve cable stress. • 48 x steel splice included

Part no. LVO233845
