S TRU CT U R ED CA BLING

Copper plugs

RJ45 UTP plug Cat6 RJ45 STP plug Cat6
for AWG23-24 stranded/solid for AWG23-24 stranded/solid
50 pcs box 50 pcs box

REMEMBER YOUR REMEMBER YOUR
EASY-CONNECT EASY-CONNECT
TOOL: TOOL:
LVN125456 LVN125456

RJ45 plug used for mounting on stranded/solid RJ45 plug used for mounting on stranded/solid cable.
cable. New terminating principle (easy connect) New terminating principle (easy connect) simplifies
simplifies the terminating by allowing the conductors the terminating by allowing the conductors to be pulled
to be pulled through the front of the connector. through the front of the connector. The performance
The performance is optimized by the reduction of is optimized by the reduction of distance between pair
distance between pair twist and contact pins. twist and contact pins.

Part no. LVN125305 Part no. LVN125310

RJ45 UTP plug Cat6a for AWG23- RJ45 STP plug Cat6a/Cat7 for big
24 stranded/solid conductor diameter cable AWG22-24 stranded/
solid conductor

REMEMBER YOUR REMEMBER YOUR
EASY-CONNECT EASY-CONNECT
TOOL: TOOL:
LVN125456 LVN125456

RJ45 plug used for mounting on stranded/solid cable. Designed to terminate Cat6a or Cat7 cable with large
New terminating principle (easy connect) simplifies diameter. The maximum diameter is 1.45mm so the
the terminating by allowing the conductors to be 23AWG/24AWG cables can go swiftly and smoothly
pulled through the front of the connector. through these ends.

Amount Part no. Amount Part no.
50pcs LVN125306 25pcs LVN125311

RJ45 STP plug Cat6a

for AWG22-23 solid/stranded

RJ45 plug used for direct mounting on cable with large AWG
size, e.g. Cat6a. Often used for IP camera installations.
Suitable for both unshielded and shielded installations.

Part no. LVN125415 10 pcs bag
